Holster untuk perlindungan.
Indikator baterai rendah.
Backlight.
Features
Autorange
Compact And Easy To Use
3999 Counts
Frequency, duty cycle, capacitance, and temperature measurement
FUNCTION RANGE ACCURACY RESOLUTION
DC Voltage 400m/4/40/400V (0.5%+4d) 100/1m/10m/100mV
600V (1%+4d) 1V
AC Voltage 4/40/400V (0.8%+6d) 1m/10m/100mV
600V (1%+6d) 1V
DC Current 400/4m/40m/400mA (1%+10d) 0.1/1/10/100A
10A (1.2%+10d) 10mA
AC Current 400/4m/40m/400mA (1.5%+10d) 0.1/1/10/100A
10A (2.5%+15d) 10mA
Resistance 400 (0.8%+5d) 0.1
4k/40k/400k/4M (0.8%+4d) 1/10/100/1k
40M (1.2%+10d) 10k
Diode Test Read approximately forward voltage drop of the diode
Continuity Built-in buzzer will sound if resistance is less than 50
Capacity 4nF (5%+90d) 1pF
40n/400n/4/40F (3.5%+8d) 10p/100p/1n/10nF
100F (5%+8d) 100nF
Frequency 1/10/100/1k/10kHz (0.5%+10d) 0.001/0.01/0.1/1/10Hz
100k/1M/30MHz 100/1k/10kHz
Temperature (-20 ~ 1000)C 400C (1%+5d) 1C
400C(1.5%+15d)
Duty Cycle 0.1 ~ 99.9% For Your Reference 0.1V
Display : LCD 3999 counts
Indication : over range, low battery
Power : 2 x 1.5V (AAA size)
Size : H145 x W74 x D36mm
Weight : approx. 190g (including batteries)
Standard Accessories : instruction manual, holster, soft pouch, test leads,
K-Thermocouple, batteries, warranty card
